产品详细说明
滤材为粗效过滤棉,容尘量大，阻力低
外框为镀锌框或铝合金框
耐湿度可达100%
耐温80℃
用于空调过滤 空压机过滤 洁净室过滤等
With synthetic fiber, big dust-holding capacity, low resistance
Frame :galvanized sheet or aluminum alloy
Humidity:100%
Temp.resistance:80℃
Air-condition, air compressor and clean room,etc
性能参数 specification
|
尺寸size W*H*D(mm) |
额定风量（m3/s）rated air flow |
初阻力(pa)initial resistance |
终阻力(pa)final resistance |
级别clss |
|
595*595*20mm |
1900 |
35 |
180 |
G3 |
|
290*595*20mm |
1000 |
35 |
180 |
G3 |
|
595*595*46mm |
3400 |
35 |
180 |
G3 |
|
290*595*46mm |
1700 |
35 |
180 |
G3 |
|
595*595*25mm |
1900 |
45 |
220 |
G4 |
|
290*595*25mm |
1000 |
45 |
220 |
G4 |
|
595*595*46mm |
3400 |
45 |
220 |
G4 |
|
290*595*46mm |
1700 |
45 |
220 |
G4 |
