通过认证
过滤性能好 容尘量大
滤袋边缘采用超音波方式熔合 具有良好的气密性及结合强度 不产生漏气或破裂
耐湿度强 可达100%耐湿度
耐温达80℃
空调过滤系统，无尘室，商场，医院，电子厂，喷漆房等
Non-silicone synthetic fiber by hot melting way
High efficiency，large dust-holding capacity
Ultrasonic sealing make the edge of pocket with good strength, not easy to be broken
Humidity:100%
Temp.resistance:80℃
Application：air-condition system，clean room, shopping mall, hospital, electronics factory
and painting room, etc
性能参数specification
|
尺寸(mm)size W*H*D |
级别class |
袋数bags |
过滤面积(㎡)filtration area |
额定风量(m3/s) rated air flow |
初阻力(pa)initial resistance |
终阻力(pa)final resistance |
|
287*592*550 |
G3 |
3 |
1.86 |
1700 |
15 |
200 |
|
490*592*550 |
G3 |
5 |
3.12 |
2600 |
15 |
200 |
|
592*592*550 |
G3 |
6 |
3.78 |
3400 |
15 |
200 |
|
287*592*600 |
G4 |
3 |
2.12 |
2250 |
45 |
250 |
|
490*592*600 |
G4 |
5 |
3.66 |
3650 |
45 |
250 |
|
592*592*600 |
G4 |
6 |
4.40 |
4250 |
45 |
250 |
|
287*592*600 |
F5 |
3 |
2.12 |
1700 |
60 |
300 |
|
490*592*600 |
F5 |
5 |
3.66 |
2800 |
60 |
300 |
|
592*592*600 |
F5 |
6 |
4.40 |
3400 |
60 |
300 |
